Beam racking: How Storlogi uses “hard work” to create real benefits

I. Product features: secure and flexible underlying logic

Storlogi’s beam shelves abandon flashy designs and return to the essential needs of storage:

Strong Skeleton, Uncompromising Safety

• Uprights are made of Q235B or higher-grade cold-rolled steel plates (thickness 1.5-2.5mm+), precision roll-formed into 11-13-sided structures. The sectional moment of inertia is increased by over 30%, with impact resistance far exceeding that of ordinary uprights.
• Crossbeams adopt the industry-leading “P-type welded beam” structure, with internal welded reinforcing ribs forming a rigid box-type system—far from simple bent components.
• Key connection points are equipped with lugged safety pins to ensure zero risk of crossbeam detachment under external impact.

Flexible Adaptation, Dynamic Adjustment

• With 75mm or 50mm as the adjustment modulus, the layer height can be freely adjusted as needed to cope with changes in cargo dimensions. It features strong expandability, supporting post-installation of mold racks, mezzanine platforms, or even upgrading to automated stereoscopic warehouses.

Enhanced Protection, Detailed Assurance

Optional upright foot guards, anti-collision bars, and pallet back nets can improve safety by over 50% in areas with frequent forklift operations.

II. Product Parameters: Quantified Expressions for Precise Matching

Storlogi’s shelving parameters aren’t just numbers on paper—each one is validated through real-world operational scenarios!

Dimensions in mm: Mastering space utilization like a pro

• Length: Tailored to pallet sizes. For a common 1200mm pallet, the shelf length is designed as 2700mm (1200×2+300), leaving just the right gap between pallets for effortless loading/unloading.
• Depth: 100mm shorter than pallet depth. If the pallet is 1000mm deep, the shelf depth is 900mm—a smart design to perfectly avoid forklift scraping during operation.
• Height: Designed in 75mm integer multiples, with a 500mm safety buffer reserved at the top layer for both order and security.

Hardcore performance: Backed by real-world test data

Maximum height: Stable even in 12-meter high-rise warehouses—steady as a rock, use with confidence!

Single-layer load-bearing: Handles 1000kg-5000kg with ease. Customized higher loads are available—when it comes to bearing capacity, Storlogi “never backs down”!

Surface treatment: Two ultra-durable options! Powder coating (film thickness 60-80μm) or hot-dip galvanizing (zinc layer ≥80μm), both passing salt spray tests exceeding 1000 hours—rust resistance at its finest!
